Introduction
Millimeter-wave (mmWave) sensors have become essential in automotive safety, industrial automation, UAV navigation, and security systems. A common question among engineers and system designers is: “What frequency do mmWave sensors use?”
The operating frequency determines a sensor’s range, resolution, penetration capability, and suitability for specific applications. Linpowave develops high-precision mmWave sensors optimized for performance, reliability, and compliance with global standards. This article explores operating frequency bands, technical implications, and application guidance for industry decision-makers.
1. mmWave Sensor Frequency Bands
Millimeter-wave refers to electromagnetic waves with wavelengths from 1 to 10 millimeters, corresponding to frequencies between 30 GHz and 300 GHz.
| Frequency Band | Wavelength | Typical Applications | Key Points |
|---|---|---|---|
| 24–29 GHz | 12–10 mm | Short-range automotive radar, industrial monitoring | Lower atmospheric attenuation, moderate resolution |
| 60–64 GHz | 5–4.7 mm | Industrial sensors, UAV navigation, medium-range detection | ISM band license-free in some regions |
| 76–81 GHz | 3.95–3.7 mm | Automotive long-range radar, high-resolution applications | High spatial resolution, all-weather reliability |
Linpowave focuses on 77–81 GHz sensors, widely adopted for automotive and industrial high-precision applications.
2. Frequency Impacts on Sensor Performance
-
Detection Range
-
Lower frequencies (24 GHz) slightly improve range for large targets.
-
Higher frequencies (77–81 GHz) provide precise resolution with stable performance, even in complex environments.
-
-
Spatial Resolution
-
Higher frequencies improve angular and distance resolution.
-
77–81 GHz sensors can distinguish small targets (pedestrians, drones) at medium to long distances.
-
-
Material Penetration
-
24 GHz penetrates thin non-metallic obstacles better than higher frequencies.
-
77–81 GHz provides accurate detection but is sensitive to environmental attenuation.
-
-
Antenna Size and Design
-
Higher frequencies allow smaller antennas while maintaining narrow beamwidth, enabling compact sensor integration.
-
3. Practical Applications by Frequency
Automotive Radar
-
Long-Range Radar (LRR): 77–81 GHz → adaptive cruise control, highway safety, collision avoidance.
-
Short-Range Radar (SRR): 24–77 GHz → parking assistance, blind-spot monitoring, pedestrian detection.
Industrial Automation
-
60–64 GHz → robotic arms, material tracking, factory automation; balances range and resolution.
UAV Navigation
-
60–77 GHz → obstacle detection, altitude measurement, precise navigation; higher frequencies improve angular resolution.
Security and Surveillance
-
24–77 GHz → human detection, motion tracking; higher frequencies increase motion detection accuracy for small objects.
4. Regulatory Compliance
Different countries regulate mmWave sensor frequency bands to avoid interference:
| Region | Permitted Bands | Notes |
|---|---|---|
| USA | 24.0–24.25 GHz, 76–81 GHz | Automotive and industrial use |
| Europe | 24.05–24.25 GHz, 76–81 GHz | Automotive radar standard |
| China | 24.05–24.25 GHz, 77–81 GHz | Automotive radar standard |
Linpowave ensures all sensors comply with regional regulations, enabling safe global deployment.
5. Frequency Selection Guidelines
Considerations:
-
Application Type – Long-range automotive (77–81 GHz), short-range automotive (24–77 GHz), industrial monitoring (60–64 GHz), UAV (60–77 GHz).
-
Target Characteristics – Larger targets can be detected with lower frequencies; small targets need higher frequencies.
-
Environmental Conditions – Rain, fog, snow affect higher frequencies; Linpowave sensors use adaptive processing.
-
Compliance – Ensure selection meets local regulatory requirements.
6. FAQs About mmWave Sensor Frequencies
Q1: Why do automotive radars prefer 77–81 GHz?
-
This band balances resolution, range, and regulatory compliance, enabling accurate detection of vehicles and pedestrians, even in adverse weather.
Q2: Can 24 GHz sensors detect small targets accurately?
-
24 GHz is better for large objects at short range. High-resolution small-target detection requires 77–81 GHz.
Q3: Are mmWave sensors all-weather capable?
-
Yes, Linpowave sensors maintain reliable operation in rain, fog, and snow using advanced signal processing.
Q4: How does frequency influence sensor size?
-
Higher frequencies allow compact antenna design without sacrificing beamwidth or accuracy.
7. Summary
Frequency selection is critical for mmWave sensor performance.
-
24 GHz: Short-range, penetrates thin obstacles, cost-effective, suitable for SRR and industrial monitoring.
-
60–64 GHz: Medium-range industrial and UAV applications, balance of range and resolution.
-
77–81 GHz: High-resolution, long-range automotive radar, UAV, and industrial use.
Linpowave sensors optimize frequency for each application, delivering high precision, all-weather reliability, and global compliance. Choosing the right frequency ensures effective detection, precise tracking, and reliable operation in automotive, industrial, UAV, and security systems.
