introduction
In the fields of smart industry, robotics, and home automation, accurately measuring the distance to static objects is fundamental. While millimeter-wave (mmWave) radar is widely applied in motion detection, gesture recognition, and security monitoring, its potential in static object distance measurement is often overlooked. Yet, whether for indoor mapping, furniture localization, or industrial equipment monitoring, precise knowledge of the distances to walls, furniture, or machinery is essential.
Many developers notice that most radar modules on the market are optimized for human detection or motion sensing, often filtering out static objects or providing inaccurate measurements. This limitation reduces the usefulness of mmWave radar in broader applications. To achieve high-precision, reliable static distance measurements, it is critical to understand radar principles, leverage proper signal processing methods, and choose the right hardware modules with suitable calibration strategies.
The Principles and Advantages of Static Object Measurement with mmWave Radar
The core principle of radar distance measurement is detecting the time delay or phase difference between the emitted and received electromagnetic waves to calculate the distance to a target. Compared to optical or infrared sensors, mmWave radar offers strong penetration, is insensitive to lighting conditions, and can provide stable measurements even in dark or smoky environments.
Time-of-Flight (ToF) measurement is a straightforward approach. The radar emits high-frequency signals and measures the time it takes for the signals to return after reflecting from an object. The distance is calculated as:
Distance=c×t2Distance = \frac{c \times t}{2}
where cc is the speed of light, and tt is the signal travel time. To achieve centimeter-level accuracy, millimeter-wave radars operate in the 60–80 GHz range with high-speed ADC sampling.
Another precise approach is phase-based measurement. By comparing the phase of the transmitted signal with the returned signal, radar can achieve sub-centimeter accuracy for static objects. Unlike Doppler-based motion detection, phase measurement does not require the target to move, making it ideal for robotics, indoor mapping, and industrial monitoring.
Frequency-Modulated Continuous Wave (FMCW) radar is commonly used for static distance measurement. By emitting a linearly modulated frequency sweep and analyzing the frequency difference of the return signal, FMCW radar can provide accurate distance data even for stationary targets, unaffected by lighting or minor occlusions. This reliability makes it superior to conventional infrared or ultrasonic sensors in complex environments.
Accuracy and Environmental Considerations
The measurement accuracy of mmWave radar depends mainly on bandwidth, operating frequency, and sampling rate. Higher bandwidth improves distance resolution, and faster sampling yields finer data for reliable measurement. For example, a 60 GHz radar with 4 GHz bandwidth can theoretically achieve approximately 3.75 cm resolution. With multiple measurements and averaging, actual accuracy often stabilizes within 2–5 cm.
Environmental factors such as multipath reflections and noise can affect measurements. Walls, metallic furniture, or floors may create overlapping signals, causing deviations. Techniques to mitigate these issues include: performing Fast Fourier Transform (FFT) to isolate the primary echo, averaging multiple points on large surfaces, and enabling temperature compensation to reduce drift. Setting a return signal threshold also helps filter out minor objects or clutter, leaving only the main target signal and ensuring stable static distance measurements.
Linpowave Modules and Development Kits
Choosing the right radar module is critical for static distance measurement. Linpowave offers mmWave radar modules with high resolution, low power consumption, compact design, and rich development support, suitable for various scenarios. Key features include:
-
High frequency (60 GHz) for fine spatial resolution, ideal for indoor and short-range measurements
-
≥4 GHz bandwidth for centimeter-level distance accuracy
-
Access to raw data for custom algorithm development
-
Low power (<0.5 W), suitable for robotics, portable devices, and smart home integration
-
Python, MATLAB, and C++ SDK examples supporting point cloud and FFT data processing
When using these modules, it is recommended to carefully plan the installation angle and position to cover the target area while avoiding strong reflections from ceilings, floors, or large metal surfaces. After installation, sensitivity and filter parameters should be adjusted according to the environment, and multi-point sampling strategies should be used to improve stability. Proper signal processing and temperature compensation can further minimize environmental interference.
Practical Operation and Case Studies
In practice, mmWave radar can accurately measure distances to walls, furniture, and industrial equipment. In a controlled lab environment using a Linpowave 60 GHz module, distances to a living room wall, desk, and industrial shelf were measured:
| Target | Measured Distance | Accuracy | Method |
|---|---|---|---|
| Living Room Wall | 3.12 m | ±0.03 m | Multi-point averaging |
| Desk | 1.25 m | ±0.02 m | Single-surface calibration |
| Industrial Shelf | 4.87 m | ±0.05 m | High-reflection surface filtering |
Through multi-point sampling and signal processing, radar demonstrated high stability and reliability for static targets. For large walls or complex furniture layouts, multiple scans can generate 2D or 3D maps, providing precise data for robot navigation, indoor layout modeling, or industrial automation.
Applications
The potential applications for mmWave radar in static distance measurement are extensive.
Robotics and SLAM: Static distance data from radar can be directly used to generate point cloud maps of indoor or industrial environments. Unlike vision-based sensors, radar is unaffected by light conditions and provides reliable data in dark or smoky conditions, ensuring robust robot perception.
Industrial Automation: Radar can measure the position of shelves or machinery to support automated monitoring and safety alarms. Compared to cameras, radar is less affected by occlusion, delivering consistent data.
Smart Home: mmWave radar can detect furniture placement and room layout, integrating with smart lighting or HVAC systems to optimize environmental adjustments. For instance, if furniture is moved, the system can automatically adjust lighting zones or airflow directions, enhancing comfort and smart living experiences.
FAQ
Q1: Can mmWave radar measure walls and furniture?
Yes. Both Time-of-Flight and phase-based methods provide centimeter-level accuracy.
Q2: What is the typical range and accuracy?
Ranges from 0.1–10 meters, with 2–5 cm accuracy.
Q3: Is raw data access necessary?
Yes. Motion-optimized modules may filter out static objects; raw data access allows custom algorithms.
Q4: Which modules are suitable for static measurement?
Linpowave compact modules and development kits support static distance measurement, raw data output, and SDK examples.
Q5: Can entire rooms be mapped?
Yes. Multi-point sampling and data fusion can generate 2D or 3D room maps.
Q6: Is indoor use safe?
Completely safe. Low-power mmWave signals are harmless to humans and pets.
Conclusion
Millimeter-wave radar excels not only in motion detection but also in static object distance measurement. By selecting the right module, calibrating parameters, and applying proper signal processing, developers can achieve centimeter-level accuracy, providing reliable data for robotics, industrial automation, and smart home applications. Linpowave’s high-resolution, low-power radar modules and development kits make it easy to implement mmWave technology across a variety of static measurement scenarios, advancing intelligent environmental sensing and automation.
